Model S-2007



The S-2007 flowmeter uses the Pitot tube principle for measurement. The body of the flowmeter is made of polymethacrylate PMMA with a maximum heat resistance of 70 ° C. The flowmeter is fixed to the pipe with two metal straps.

Maximal thermal endurance: 70 °C
Maximal working pressure: 10 bar
Accuracy: +/- 10 %.


Type

Wter l/min max.

DN

Ø

S-40 330 40 1 ½“
S-50 560 50 2”
S-65 900 65 2 ½“
S-80 1200 80 3”
S-100 2000 100 4”
S-125 3000 125 5”
S-150 4500 150 6”
S-200 7200 200 8”



Notice:

It is a need to set the flowmeter in the position which is essential for keeping the accuracy of the measurement. The pipe lying in front of the flowmeter should be flat in the length of 10x of the pipe dimension (10xDN) and behind of the flowmeter should be flat in the length of 4x of the pipe dimension (4xDN).





Flowmeter S-2007Flowmeter S-2007 dimensions

If you are interested in price offer, please, fill in our inquiry form.
